VOLTAGE: 1 X 9V
- CURRENT: 1 X 0.078A
- ISOLATION RESISTANCE: >5MOHM / 500VDC
- ELECTRIC STRENGTH: >5KV MIN.
- DESIGNED FOR AN AMBIENT TEMPERATURE OF MAX. 40°C
- THERMAL CLASS E, MATERIALS TO MAX. 120°
- SHORT-CIRCUIT PROTECTION UP TO 3VA
- POSSIBILITY OF THERMAL FUSE PROTECTION
- MAX. TEMPERATURE FOR CLASS E: 95°C
- PRIMARY TENSION: 230V ± 10%, 50/60HZ
- SECONDARY VOLTAGE TOLERANCE: +7% - 3% AT 230V AND MAX. LOAD
- PERFECT SOLDERABILITY FOR WAVE BATH
- CE LABELLED
- CREEPAGE DISTANCES AND CLEARANCES ACCORDING TO IEC742
- PICTURE:
-
- 1*: BOBBIN WITH TWO CHAMBERS
-
- 2*: INPUT WINDING
-
- 3*: ENCAPSULATION IN EPOXY RESIN
-
- 4*: OUTPUT WINDING
-
- 5*: CONNECTION PINS
-
- 6*: POLYAMIDE COVER
-
- 7*: MAGNETIC CORE
-
- 8*: SAFETY TRANSFORMER
-
- 9*: INHERENTLY SHORT-CIRCUIT PROOF
-
- 10*: PRIMARY VOLTAGE
-
- 11*: NOMINAL POWER / TEMPERATURE
-
- 12*: MANUFACTURER'S REFERENCE
-
- 13*: ORDERCODE
-
- 14*: MEETS :
-
- 15*: NOMINAL SECONDARY VOLTAGES - Velleman

Encapsulated Transformer 0.7va 1 X 9v / 1 X 0.078a
