housing: grey ABS • miniature magnetic switch NC (when activated by magnet) • screw mountingcontact: NC • switching voltage (max): 1-50 V AC/DC • switching current (max.): 100 mA • contact capacity (max.): 5 W • initial contact: 0.2 ohm max. • carry current (max.): 100 mA • breakdown voltage: 150 VDC • insulation resistance: 100M ohm min. • switch cycle: 5 x 10 (7) @ 12 VDC, 50 mA • with leads (on switch): 300 mm • operating gap: max. 23 mm • dimensions: 34 x 15 x 8 mm
