type: ON-OFF SPST • cap: amber • remark: with amber LED light 2 V at 10 mA (a current limiting resistor has to be used) • contact rating: 5A/250Vac, 10A/125Vac • drill Ø: 20mm • electrical life: 10000 actuations at full load • mechanical life: 50000 operations • contact resistance: <20ohm • insulation resistance: 1000Mohm • dielectric strength: •• >1500V: 1 minute •• >3000V: between poles • operating temperature: -30°C to +85°C • materials: •• housing: 66 nylon (UL94V-2) •• actuator: 66 nylon (UL94V-2) •• movable contacts: copper, silver-plated •• stationary contacts: copper, silver-plated •• terminals: copper, silver-plated •• contact: spring-loaded

Interruptor Rocker com LED Ambar - 5a-250v Spst On-Off - com Luz LED Ambar
