Tp-Link Mc110cs - Fiber Media Converter - 10mb Lan, 100mb Lan

32,30 €

Buy

Tp-Link Mc110cs - Fiber Media Converter - 10mb Lan, 100mb Lan

Ref.: MC110CS

Warranty: Learn more Condition: Novo

Compare

Bookmark

Ver Vídeo

Tp-Link Mc110cs - Fiber Media Converter - 10mb Lan, 100mb Lan

Store: 32,60 €

32,30 €

Units

3 units1%32,00 €

6 + units2%31,73 €

Buy

Availability

Expected delivery to 9 of June

The period indicated corresponds to an estimated period of 4 working days to mainland Portugal. Islands (Azores and Madeira) plus an estimated period of 10 more working days to the indicated period. Estimated period valid only for the existing quantity in stock. The estimated period may change depending on availability or times subject to delays (Example: Black Friday, Christmas, Contingency States, among others).

OnlineAvailable

Expected delivery at 9 of June.
Learn more

Armazém CentralUnavailableLearn more

No possibility of withdrawal.

Store Porto - Júlio de MatosBy OrderLearn more

Levantamento previsto a 6 of June.
Period valid for online purchases

View survey points

Technical Data Sheet{"pt":[{"name":"Rede","group":true},{"name":"Taxa m\u00e1xima de transfer\u00eancia de dados","value":"100 Mbit\/s","info":"A velocidae massima que os datas sao traferidos da un dispositivo ate o outro"},{"name":"Normas de Comunica\u00e7\u00f5es","value":"IEEE 802.3,IEEE 802.3u,IEEE 802.3x","info":"The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g."},{"name":"Taxa de transfer\u00eancia de dados Ethernet LAN","value":"10,100 Mbit\/s","info":"The different speed levels of the Ethernet LAN connection."},{"name":"Tecnologia de cablagem ethernet de cobre","value":"10BASE-T,100BASE-FX,100BASE-T","info":""},{"name":"Auto MDI\/MDI-X","value":"Sim","info":"A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link."},{"name":"Sistema duplex","value":"Completa, Half","info":"A duplex communication system is a point-to-point system composed of two connected parties or devices that can communicate with one another in both directions, simultaneously."},{"name":"Tipos de cabos suportados","value":"Cat3,Cat4,Cat5","info":""},{"name":"Conectividade","group":true},{"name":"Tecnologia de conetividade","value":"Com fios","info":"The technology that enables connectivity of the device, e.g. wired or wireless."},{"name":"Quantidade de portas Ethernet LAN (RJ-45)","value":"1","info":"Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet."},{"name":"Portas Fibre channel","value":"1","info":"The number of sockets (ports) for fibers (cables)."},{"name":"Conector de fibra \u00f3ptica","value":"SC","info":"This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced."},{"name":"Desempenho","group":true},{"name":"Dist\u00e2ncia m\u00e1xima de transfer\u00eancia","value":"12500 m","info":"The greatest distance over which the data\/signal can be transferred."},{"name":"Comprimento de onda","value":"1310 nm","info":"The distance over which a wave repeats itself. The wavelength determines the characteristics of the wave e.g. red light has a different wavelength to blue light."},{"name":"Modo de estrutura de fibra","value":"Modo individual","info":""},{"name":"Design","group":true},{"name":"Interno","value":"N\u00e3o","info":"o dispositivo \u00e8 integrado ou precisa de se integrado (sim ou nao), No signfica que o dispositivo \u00e8 collegato externamente via cavo ou wireless"},{"name":"Indicadores LED","value":"Sim","info":""},{"name":"Cor do produto","value":"Preto","info":"The colour e.g. red, blue, green, black, white."},{"name":"Conformidade com RoHS","value":"Sim","info":"The Restriction of Hazardous Substances (RoHS) Directive aims to restrict certain dangerous substances commonly used in electrical and electronic equipment. Any RoHS compliant product is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). PBB and PBDE are flame retardants used in several plastics. For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials. Any RoHS compliant component must have 100 ppm or less of mercury and the mercury must not have been intentionally added to the component. In the EU, some military and medical equipment are exempt from RoHS compliance."},{"name":"Gest\u00e3o de energia","group":true},{"name":"Consumo de energia (m\u00e1x)","value":"2,4 W","info":"The maximum amount of power used by the device."},{"name":"Pesos e dimens\u00f5es","group":true},{"name":"Comprimento","value":"95 mm","info":"The measurement or extent of something from side to side."},{"name":"Largura","value":"73 mm","info":"The distance from the front to the back of something."},{"name":"Altura","value":"27 mm","info":"The measurement of the product from head to foot or from base to top."},{"name":"Condi\u00e7\u00f5es ambientais","group":true},{"name":"Temperatura de funcionamento","value":"0 - 40 \u00b0C","info":"The minimum and maximum temperatures at which the product can be safely operated."},{"name":"Limite de temperaturas (armazenamento)","value":"-40 - 70 \u00b0C","info":"The minimum and maximum temperatures at which the product can be safely stored."},{"name":"Gama de humidade relativa de opera\u00e7\u00e3o","value":"10 - 90%","info":""},{"name":"Humidade de n\u00e3o funcionamento","value":"5 - 90%","info":""}]}
Specifications
Evaluations

The MC110CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC110CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC110CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on both transmitting and receiving data.
Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINK's 19" system chassis, Auto MDI/MDI-X for TX port, auto negotiation of duplex mode on TX port, and front panel status LEDs. The MC110CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers.
