Output power: Up to 7.4 kW, 32 A, single phase
Input voltage: 230 VAC (single phase)
Charging mode: Mode 3
Network connection: Compatible with TN, TT and IT systems
Output cable and connector:
Type 2 connector (cabled version); 5m long cable
Connectivity:
802.11 b/g/n 2.4 Ghz Wif
Bluetooth ready for easy setup and local connection
Authentication:
Open Access:
Connect&Charge mode
Private access: option to enable authentication via RFID card/app
Smart Charging App: App to set charge configuration and power level, monitor charging sessions and energy consumption, remotely schedule and start charging, receive notifications and access more smart charging features
Additional services for business customers:
Web control panel to facilitate complete management of the company's EV fleet and monitor charging trends
The app was specifically designed to meet the needs of companies and allows charging at company stations, controlling energy consumption and receiving notifications about charging sessions
Demand Limitation Pro:
Ready for Demand Limitation Pro function: this function will allow you to always charge at the maximum available power without exceeding it
LED Lights: Dynamic LED lights that show charging status
Dimensions and weight:
153mm x 180mm x 421mm
10 kg for cable version
Cashier:
IP55; IK08
Back plate connection for easy installation
Protection: Internal DC current leakage detector (above 6 mA) Low cost external type A residual current device and mandatory miniature circuit breaker
Firmware and protocols:
Firmware with wireless updates (OTA)
Continuous, long-term data storage in the event of a power failure
Compliant with OCPP 1.6J
Temperature range: From -40 °C to +60 °C
Accuracy: Measurement accuracy: 0.5%.
Standards and certifications:
IEC 61851-1 (2017)
CE certificate - Endesa X
